Patch.
Mic.
Visualize.

Inspect any unit

Click any rack unit or patchbay — or tap its ⓘ in the rack panel — for a product photo, brand and category, and a live input/output summary read straight from the routing model, so the specs can never drift from the patch.

XLR and TRS know the difference

Every endpoint carries its physical connector type. Pure XLR, pure TRS, and combi sockets are modeled separately, so impossible patch choices are blocked before they become bad paperwork.

+48V phantom checks

Condenser cards are flagged +48V. Signal flow stops at any mic that hits a phantom input without power — but its siblings on the same interface keep flowing, so one dead mic never blacks out the whole desk.

One plug per jack

A real connectivity engine enforces one-plug-per-jack behavior, connector compatibility, normalling state, and active signal resolution as you patch.

Two bays, side by side

A normalled TRS bay — switch half/full per module and watch the rear routing change — mounted next to a straight-through XLR bay for mic-level patching.

Swap the whole rack

Drop in real outboard across 30 hot-swappable slots — pick from a categorized menu split into audio interfaces and analog gear.

Save, recall, undo

Full undo/redo history and portable .bpatch session files — now with microphones, phantom state, session title, room, and notes baked in. Pick up exactly where you left off.

Document the whole room

Turn a session into paperwork you can wire from. Every export is built from the live routing — nothing retyped, nothing drifts.

• Wiring PDF Rear wiring by jack number, front patches by cable colour, a normalled-route map, mic paths, phantom warnings, and automatic routing warnings.
• Label strips Printable front & rear patchbay labels, named from the gear each point connects to — print, cut, done.
• Session notes Title, room, and notes saved in the .bpatch and printed on the report, so you remember why a layout exists.
